Panel brand: AUO
Panel model: M150XN07 V.1
Compatible Model: M150XN07 V.2
Panel type: a-Si TFT-LCD
Panel size:15.0"
Display Area: 304.10 * 228.10mm
Outline Size:326.5 x 253.5 x 12.0mm
Resolution: 1024*768
Display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel Brightness: 250 cd/㎡(Typ.)
Contrast: 500:1 (Typ.)
Display Color: 16.2M (6-bit)
Response Time: 3ms
Visual Angle: 65/65/65/55 (Typ.)(CR≥10) (L/R/U/D)
Scanning Frequency:60Hz
Signal Connector: LVDS
Backlight: 2CCFL
Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
