Panel brand: INNOLUX
Panel model: AT070TNA2 V.1
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 7.0" (inch)
Resolution:1024*600
Width Height Rate: 17:10
The display mode: TN, Normally White, Transmission-type
Surface treatment: Mirror Face, hard-core coating (3H)
Panel brightness: 250 cd/㎡(Typ.)
Contrast: 700:1 (Typ.)
Display color: 262K/16.7M (6-bit / 6-bit + Dithering)
Response Time: 10/15(Typ.) (Tr/Td)(ms)
Visual Angle: 75/75/70/75(Typ.) (CR ≧ 10) (L/R/U/D)
Lamp Type: 3S6P WLED
Singal Connector: LVDS ( 1ch, 6/8-bit)
Panel Voltage: 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL)
Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
