AT080TN52 V.1 LCD Display Screen 8 inch 800*600 LCD Panel

$72.99
LCD-INN-300110-ZKL-036

Quantity Discount
5 +
$69.34
10 +
$67.88
15 +
$66.42
20 +
$65.69
30 +
$64.23
*The discount will be reflected in the payment.
  • Shipping Weight: 1kg
  • Units in Stock : 984
  • Manufactured by: Innolux
  • This product was added to our catalog on Thursday 10 January, 2013.
Description

Panel brand: INNOLUX
Panel model: AT080TN52 V.1
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 8.0" (inch)
Active area: 162.0(W) × 121.5(H) mm
Module size: 183.0(W) × 141.0(H) × 5.6(D) mm
Resolution: 800*600
The display mode: TN, Normally White, Transmissive
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 350 cd/㎡(Typ.)
Contrast:500:1 (Typ.)
Display color: 262K  (6-bit)
Response Time: 10/15(Typ.) (Tr/Td)(ms)
Visual Angle: 70/70/50/70(Typ.) (CR ≧ 10) (L/R/U/D)
Lamp Type: 3S9P WLED
Singal Connector: Parallel RGB ( 1ch, 6/8-bit)
Panel Voltage: 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military,Train LCD Media player, Portable DVD, Car Mobile media etc.
