Panel brand: INNOLUX
Panel model: AT102TN03 V.9
Panel type: a-Si TFT-LCD
Panel size: 10.2"(inches)
Visual Area: 222(W)X132.48(H)mm
Outline Size: 235.0*145.8*5.9mm
Display proportion: 16:9
Resolution:800*480
Display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel Brightness: 250 cd/㎡(Typ.)
Contrast: 300:1 (Typ.)
Display Color: 262K (6-bit)
Response Time: 10/15 (Typ.)(Tr/Td) (ms)
Visual Angle: 80/80/70/80 (Typ.)(CR≥10) (L/R/U/D)
Scanning Frequency:60Hz
Lamp Type: WLED
Signal Connector: Parallel RGB (1 ch, 8-bit) + SPI
Connector: double 30pins
Panel voltage: 3.3V (Typ.)
Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
