Basic Specification:
Productor: PVI
MODEL: PM061WX1
Size: 6.1"
Resolution: 800x480
Resolution Name: #39;clock
Display scale: 17:9
Pixel Arrangement: WVGA
Pixel Pitch: 0.05675x0.150 mm
Panel Composition: LCD Screen
Technology: a-Si
Applications: Portable DVD, Car Mobile media
Panel Features: Matte, UP/Down, Left/Right Rolling over to display, normally white, LED backlight, the backlight life is over 50,000 hours, widescreen.
Photoelectric Parameters:
Luminance: 500 nits
Contrast Ratio: 400 :1
Color: 262K(6bit)
Color Saturation: RGB Vertical Stripe
Response Time: 10/15(Tr/Td) ms
Viewing Angle: 75/75/50/70 (U/D/L/R)
The Best View Angel: 6o degrees
White Field Chroma: X:0.310;Y:0.340
White Field Dynamic: X:0.310;Y:0.340
Scanning Frequency: 1.25/1.33(Typ./Max.)(9points)
Reverse Scan: Overturn (horizontal/Vertical)
Interface: TTL(1ch,6bit)
Singnal Interface Definition: Parallel RGB
Drive-screen voltage: 3.3/3.3/9.5/17/-8V(VCC/VDD1/VDD2/VGG/VEE)
Input Current: 30A
Kind of Singnal Interface: FPC
Brand of Singnal Interface: FPC
Pitch of Singnal Interface: 2 mm
Quantity of Singnal Interface: 2 pcs
Pin of Singnal Interface: 0.5 pins
Structural Parameters:
Operation Temperature: -30 C ~ 85 C
Storage Temperature: -40oC ~ 95oC
Weight: 120±10 g
Surface Technology: Matte
Active Area: 136.2x72.0 mm
Display Area: 139.2x75.0
Outline: 149.0x82.9x6.2 mm
Touch Panel: No
CCFL Position: BLE-2PINS-AC
Backlight) White LED
Lamp Number: 3S10P pcs
CCFL Shape: Side into type illuminant
Life Time of Lamp: 50K Hours
Voltage of Lamp: Array
Current of Lamp: 10.4
Working frequency of BL: 240mA
Driver of Backlight: 1.248W
Backlight Interface: Overturn (horizontal/Vertical)
Brand of Backlight Interface: Connector
Model of Backlight Interface: JST
Quantity of Backlight Interface: BHSR-02VS-1 pcs
Pitch of Backlight Interface: 1 mm
Backlight Interface Define: 3.5
